Feuling Parts High Flow Camplate – ’17-’26 M8

Description

• Product Description
• Vehicle Fitment

• • Increase engine oil flow and volume by enlarging the oil pump reservoirs and critical oil passages including the scavenging return holes from the pump to the camplate and into the engine case
  • Camplate matches the oil port holes on the camplate to the oil holes in the engine case to increase oil flow throughout the engine
  • Lowers engine temperatures by 15-25 degrees and oil running temperature by 15°-25° when matched with a Feuling® HP+ or RS oil pump
  • 7075 billet aluminum construction, which is 50% harder and stronger than the factory cast and Feuling® OE+ camplates
  • Increases the strength and hardness of the camplate, holding tighter tolerances under temperature and eliminating flexing and the need for bronze bushings
  • When matched with the Feuling® Race Series Oil Pump, rear wheel power gains of 2 horsepower and 2 ft. lb. of torque can be achieved
  • Made in the USA

  Notes

  • For gear or chain drive cams (block-off plate PART 0932-0036 required when using gear drive cams).
  • Use Only with Feuling® HP+ and Race Series M-Eight oil pumps.

• Feuling Parts 0932-0192 Vehicle Fitment & Compatibility

  Fitment data lists this product for 241 model-year applications across 1 makes, with listed model years from 2017 through 2026.

  Harley-Davidson (241 model-year applications)

  Model

  Submodel / Trim	Years
  Breakout	FXBR 107	2018, 2019
  Breakout	FXBR 117	2023, 2024, 2025, 2026
  Breakout	FXBRS 114	2018, 2019, 2020
  CVO	Limited FLHTKSE	2017, 2018, 2019, 2020, 2021
  CVO Road Glide	FLTRXSE	2018, 2019, 2020, 2021, 2022, 2023, 2024, 2025
  CVO Road Glide	FLTRXSTSE ST	2024
  CVO Road Glide	Limited FLTRKSE	2022, 2023
  CVO Road Glide RR	FLTRXRRSE	2025
  CVO Road Glide ST	FLTRXSTSE	2025-2026
  CVO Street Glide	FLHXSE	2026
  CVO Street Glide 3 Limited	FLHLTSE	2026
  CVO Street Glide Limited	FLHXLSE	2026
  CVO Street Glide ST	FLHXSTSE	2026
  CVO Tri Glide	FLHTCUTGSE	2020-2022
  Deluxe	FLDE 107	2018-2020
  Electra Glide	Highway King FLHFB	2023
  Electra Glide	Standard FLHT	2019-2022
  Electra Glide	Ultra Classic FLHTCU	2017-2019
  Fat Bob	FXFB 107	2018-2020
  Fat Bob	FXFBS 114	2018-2023
  Fat Boy	FLFB 107	2018-2020
  Fat Boy	FLFB 117	2025-2026
  Fat Boy	FLFBS 114	2018-2024
  Fat Boy	FLSTFI Gray Ghost	2025
  Freewheeler	FLRT	2017-2025
  FXDR	FXDRS 114	2019-2020
  Heritage Classic	FLHC 107	2018-2021
  Heritage Classic	FLHC 117	2025-2026
  Heritage Classic	FLHCS 114	2018-2024
  Hydra-Glide Revival	FLI	2024
  Low Rider	FXLR 107	2018-2020
  Low Rider	ST FXLRST 117	2022
  Low Rider S	FXLRS 114	2020-2021
  Low Rider S	FXLRS 117	2022-2026
  Low Rider ST	FXLRST 117	2023-2026
  Road Glide	FLTRX	2017-2026
  Road Glide	Limited FLTRK	2020-2024
  Road Glide	Special FLTRXS	2017-2023
  Road Glide	ST FLTRXST	2022-2023
  Road Glide	Ultra FLTRU	2017-2019
  Road Glide 3	FLTRT	2023-2026
  Road Glide Limited	FLTRXL	2026
  Road King	Classic FLHRC	2017-2019
  Road King	FLHR	2017-2022
  Road King	Police FLHP	2017, 2019-2023
  Road King	Special FLHRXS	2017-2025
  Softail	Slim FLSL 107	2018-2021
  Softail	Standard FXST 107	2020-2024
  Sport Glide	FLSB 107	2018-2024
  Street Bob	FXBB 107	2018-2020
  Street Bob	FXBB 117	2025-2026
  Street Bob	FXBBS 114	2021-2024
  Street Glide	CVO FLHXSE	2017-2025
  Street Glide	FLHX	2017-2026
  Street Glide	Special FLHXS	2017-2023
  Street Glide	ST FLHXST	2022-2023
  Street Glide 3 Limited	FLHLT	2026
  Street Glide Limited	FLHXL	2026
  Street Glide Ultra	FLHXU	2025
  Tri Glide	Ultra Classic FLHTCUTG	2025
  Tri Glide	Ultra FLHTCUTG	2017-2025
  Ultra Limited	FLHTK	2017-2024
  Ultra Limited Low	FLHTKL	2017-2019
