PISTON KIT 13-14 CRF450 13:8, WOSSNER 8881DB 96.00mm, HIGH COMPRESSSION 13.8:1

Description

Piston kit 96.01mm BORE 95.97 Wossner  8881DB (STD)

HONDA
CRF450 2013 – 2014,
(High compression) (2 rings)

• Wossner forged pistons are superior in strength and design.
• Engineered to provide the best possible path for combustion chamber heat transfer to cylinder walls.
• Ellipticallydesigned toprovideamoreuniform bearing surfaceunderpistonheatexpansion,eliminatinglocalizedpressureanddistributing thrustloads moreevenly,therebypreventing pistoncollapse.
• Made in Germany.

Part No. 56-W916.B.WO.HC(oro2u.com) Honda CRF450R 2013 – 2014,
Wossner Piston 96 mm Bore (PN 8881DB)
Clips P/N CW19
Pin P/N WP028
Ring Set P/N 960ADS-2

Display (cm3) 449
Hub stroke (mm) 62.10
Clearance (mm) 0.04
Wossner compression Ratio: 13.80:1
OEM Compression ratio: 12.50:1
Dome volume (cm3) +1.50
Compression height (mm) 20.70
Theorectical weight (G)

WossnerPistons is Germany’s most prestigious forged piston and rodmanufacturer.Featuring a 25-year lineage in legendary performance inthe world of racing,the Wossner Group of companies includes ForgingGroup Monale, the Italian forgingfacility that supplies manynotableglobal powerhouse automotive and powersportsmanufacturers.Producingperformance engineered 2-stroke and 4-stroke pistons, Wossner Pistonsdesigns performance applications for snowmobiles,motorcycles,dirtbikes, ATVs, UTVs, cars, trucks, boats andwatercraft.

WossnerPistons enthusiasm for innovation is based upon the beliefthat itisonly possible to discover something new when youconstantly questionthatwhich you already know. This is one of thereasons why we areactively involvedin researching the properties oflow frictionsurfaces and in developing newsuch materials. We arein close contactwith the research departments at variouscollegesand universitiesand are currently carrying out a series of tests, together with aSwiss institution, into friction reduction. In closecooperationwiththe R&D departments at leading motormanufacturers we develop high performance prototype pistons.

In order to guarantee the highestquality Wossner Pistons productionmachineshave been speciallycustomized to meet our requirements andare constantly beingfurtherdeveloped – the close cooperationbetween our engineers and themanufacturersis highly beneficial toboth parties. In order toguarantee the precision andconsistency ofthe end products, our CNCmachines are housed in an air conditioned environment. Wossner Pistonsexpertise enables us produce one-offpistons toindividualspecifications.
